Frontlit:
Laminated Frontlit Coated Frontlit
Most popular frontlit banner. Available in Super smooth and super glossy surface. The maximum width reachs 5m. Coated Frontlit is widely used in Europe and any other high quality requested places. The maximum width reachs 5m.
Features:
1) Highly Cost Effective
2) Ultra Smooth
3) Super Glossy
4) Excellent Color Reproduction
5) Gray/Black Back Available in All Items
6) Favorable Chemical Stability
7) Outdoor Durability and Weather Resistant (FR, UV, Rain, Fungi, Frost, etc.)
1) High Strength
2) High Smooth
3) Versatile
4) Excellent Color Reproduction
5) Favorable Chemical Stability
6) Outdoor Durability and Weather Resistant (FR, UV, Rain, Fungi, Frost, etc.)
Applications:
1) Billboard
2) Commercial Sign
3) Indoor and outdoor displays
4) Building signage
5) Election Banner
1) Billboard
2) Truck Cover
3) Commercial Sign
4) Indoor and outdoor displays
5) Building signage
Compatible Ink:
SOL/ECO SOL/UV/LATEX/SCREEN
SOL/ECO SOL/UV/LATEX

Specifications:
Data Sheet
Item No. Base Fabric Weight Tensile strength Tear strength
gsm / oz N/5cm N/5cm
Laminated Frontlit (All the items available in Glossy / Matte surface, White / Gray / Black Back)
AF23-280 200D*300D 18*12/inch 280 / 8 520 280 105 75
AF23-340 200D*300D 18*12/inch 340 / 10 550 300 110 80
AF35-340 300D*500D 18*12/inch 340 / 10 619 420 115 90
AF35-440 300D*500D 18*12/inch 440 / 13 745 650 200 150
AF55-280 500D*500D 9*9/inch 280 / 8 760 580 135 99
AF55-340 500D*500D 9*9/inch 340 / 10 780 600 165 120
AF55-440 500D*500D 9*9/inch 440 / 13 845 700 210 180
AF846-280 840D*840D 6*6/inch 280 / 8 980 780 190 178
AF84-440 840D*840D 9*9/inch 440 / 13 1260 850 222 190
AF84-510 840D*840D 9*9/inch 510 / 15 1280 870 240 200
AF10-440 1000D*1000D 9*9/inch 440 / 13 1400 1100 263 210
Coated Frontlit (All the items available in Glossy / Matte surface)
AF1018-450 1000D*1000D 18*18/inch 450 / 12 1600 1320 300 261
AF1018-510 1000D*1000D 18*18/inch 510 / 15 1700 1320 310 268
Note: Above mentioned physical properties are average of test results, provided for reference only.
